Outdoor Load Break Switch

FLW34-12/24 Outdoor SF6 Load Break Switch
Rated voltage (kV) 12, 24
Rated frequency (Hz) 50, 60
Rated current (A) 630
4s Rated short-time withstand current (kA) 20
Rated peak withstand current (kA) 50
FLW34-12/24 Outdoor SF6 Load Break Switch
FKW18-12/24/40.5 Outdoor Air Load Break Switch
Rated voltage (kV) 12, 24, 40.5
Rated frequency (Hz) 50, 60
Rated current (A) 630
Rated short-time withstand current (kA) 20
Rated peak withstand current (kA) 50
FKW18-12/24/40.5 Outdoor Air Load Break Switch
FZW32-12/24/40.5 Outdoor Vacuum Load Break Switch
Rated voltage (kV) 12, 24, 40.5
Rated frequency (Hz) 50, 60
Rated current (A) 630, 1250
Rated short-time withstand current (kA) 20, 25
Rated peak withstand current (kA) 50, 63
FZW32-12/24/40.5 Outdoor Vacuum Load Break Switch
FZW39-27.5 Outdoor Railway Vacuum Load Break Switch
Rated voltage (kV) 27.5
Rated frequency (Hz) 50, 60
Rated current (A) 200
Rated short-time withstand current (kA) 20
Rated peak withstand current (kA) 63
FZW39-27.5 Outdoor Railway Vacuum Load Break Switch
FZW28F-12 Outdoor Vacuum Load Break Switch
Rated voltage (kV) 12
Rated frequency (Hz) 50, 60
Rated current (A) 630
Rated short-time withstand current (kA) 16
Rated peak withstand current (kA) 40
FZW28F-12 Outdoor Vacuum Load Break Switch
FZW38-12 Outdoor Vacuum Load Break Switch
Rated voltage (kV) 12
Rated frequency (Hz) 50, 60
Rated current (A) 630
3s Rated short-time withstand current (kA) 40
Rated peak withstand current (kA) 40
FZW38-12 Outdoor Vacuum Load Break Switch
VSP5-12 Outdoor Vacuum Load Break Switch
Rated voltage (kV) 12, 24
Rated current (A) 630
Rated short-circuit making current 31.5, 40, 50, 63
4s Rated short-time withstand current (kA) 12.5, 16, 20, 25
Rated peak withstand current (kA) 31.5, 40, 50, 63
VSP5-12 Outdoor Vacuum Load Break Switch
