Outdoor Automatic Circuit Sectionalizer & Recloser
CHZ7-12/17.5/24 Outdoor AC MV Auto Circuit Recloser
| Rated voltage (kV) |
12, 17.5, 24 |
| Rated frequency (Hz) |
50, 60 |
| Rated current (A) |
630, 800, 1000 |
| Rated short-time withstand current (kA) |
12.5, 16, 20, 25 |
| Rated peak withstand current (kA) |
31.5, 40, 50, 63 |
CHZ7-12/17.5/24 Outdoor AC MV Auto Circuit Recloser
CHZ Series Solid ACR Application Manual-Mail
| Rated voltage (kV) |
12，15，24，40.5 |
| Rated frequency (Hz) |
50，60 |
| Rated short-circuit breaking current (kA) |
12.5，16，20，25 |
| Rated peak withstand current (kA) |
31，40，50，63 |
| 4s Rated short-time withstand current (kA) |
12.5，16，20，25 |
CHZ Series Solid ACR Application Manual-Mail
ZW20AF-12/24 Outdoor AC MV Sectionalizer
| Rated voltage (kV) |
12 |
| Rated frequency (Hz) |
50 |
| Rated current (A) |
630, 1000 |
| Rated short-time withstand current (kA) |
20, 25 |
| Rated peak withstand current (kA) |
50, 63 |
ZW20AF-12/24 Outdoor AC MV Sectionalizer
SMART-01 Load Monitor and Control Switch
| Rated voltage (kV) |
12 |
| Rated current (A) |
630 |
| Rated short-time withstand current (kA) |
12.5, 16, 20 |
| Rated peak withstand current (kA) |
31.5, 40, 50 |
| Rated short-circuit breaking current (kA) |
20 |
SMART-01 Load Monitor and Control Switch
RB01 Outdoor AC MV Capacitor Switch
| Rated voltage (kV) |
12 |
| Rated current (A) |
630 |
| 4s Rated short-time withstand current (kA) |
12.5, 16, 20 |
| Rated peak withstand current (kA) |
31.5, 40, 50 |
| Rated short-circuit peak making current (kA) |
31.5, 40, 50 |
RB01 Outdoor AC MV Capacitor Switch
